Product Code

XY-701

Construction

(From outside to inside)

Sleeve

Aluminum Foil/Glass Fabric/Combi PVC

Aluminum Foil/Glass Fabric/Combi PVC

Aluminum Foil / Glass Fabric /

Combi PVC / VMPET

Fiberglass/Polyester

Density

/Gram Weight

16kg/m3-32kg/m3

10kg/m3-24kg/m3

100g/m2-750g/m2

Thickness

25mm/30mm

25mm / 50mm

Plastic Bag

PET

PET

PET

Inner Duct

(With hole)

Material

Single/Double Layer Aluminum Flexible Duct

Single/Double Layer Aluminum Flexible Duct

Single / Double Layer Aluminum Flexible Duct / VMPET Flexible Duct

Diameter

50mm-650mm

(2"-25")

50mm-650mm

(2"-25")

50mm-650mm

(2”-25”)

Carbon Steel Wire Diameter

0.6mm-2.5mm

0.6mm-2.5mm

0.6mm-2.5mm

Length

10m(Max)

10m(Max)

10m(Max)

Thermal Insulation

R 0.4-R 3.0

Fire Resistance

ClassA2(Max)

ClassA2(Max)

Class A2(Max)

CompressRatio

1:10

1:10

1:10

Temperature Range

-30℃/+150℃

-30℃/+150℃

-30℃/+150℃

Operating Pressure

3000Pa

3000Pa

3000Pa

Maximum Air Velocity

30m/s

30m/s

30m/s

产品编码

XY-701

构成（由外到内）

外套

铝箔/玻纤布/复合PVC

铝箔/玻纤布/复合PVC

铝箔/玻纤布/复合PVC / 镀铝膜

玻璃棉/无纺棉

密度/克重

16kg/m3-32kg/m3

10kg/m3-24kg/m3

100g/m2-750g/m2

厚度

25mm/30mm

25mm / 50mm

塑料膜

PET

PET

PET

内管(带孔)

材质

铝箔单管

铝箔单管

铝箔单管/ 镀铝膜单管

内径

50mm-650mm

(2"-25")

50mm-650mm

(2"-25")

50mm-650mm

(2”-25”)

碳素钢丝直径

0.9mm-1.3mm

0.9mm-1.3mm

0.9mm-1.3mm

标准长度

10m(Max)

10m(Max)

10m(Max)

保温系数

R 0.4-R 3.0

阻燃等级

A2级，难燃

A2级，难燃

A2级，难燃

压缩比例

10 : 1

10 : 1

10 : 1

温度范围

-30℃/+150℃

-30℃/+150℃

-30℃/+150℃

最大压力

3000Pa

3000Pa

3000Pa

最大风速

30m/s

30m/s

30m/s
